Monday - December 5, 2016

       The latest activity on this site has been ocurring under the [Electronics and Video Projects] link. I have been building a project around a very rare, one thousand dollar, image dissector tube. Trying to get something more for my investment, as it were. It's called the [PhiloCam Project] in honor of Philo T. Farnsworth, the inventor of the image dissector tube. The philoCam requires variable rate deflection and so naturally spawned the [Dual Magnetic Deflection Amplifer] project, part 2. (Part 1 was over two years ago and is not relevant today) In parallel with both of those projects, is the DC power supply project as well. Be sure to visit the pages as they have links to the associated YouTube videos. The latest one is called [Let's build a power supply], part 1.

Sunday - October 2, 2016

       I updated the [Pixicam restoration project] pages today. most recent updates are always near the bottom of the page. Making fairly good progress, replacing parts and cleaning everything prior to a first power up and stage by stage testing. Enjoy!

Sunday - August 28, 2016

       For those wondering what I have been up to, the following program should enlighten you.

       And if that were not enough already, I added the [RCA 2F21/1699 TV Monoscope Project] to the electronics and video projects pages this evening as well.

Saturday - August 27, 2016

       Just added two RCA magnetic deflection monscope tubes to my everexpanding collection of unique vacuum tubes. Got a 2F21 with Indian Head test pattern and a 1699 from TV station WEHT channel 50 in Henderson, Indiana, 1953. Getting two tubes doubles my chances of having an operational one. The 2F21, being generic, it probably has a large number of hours on it. The broadcast station tube was changed out early when the station moved to lower frequency UHF channel to increase their transmitter efficiency.

       I plan to build a solid state circuit to support these tubes. If and when such a machine is built, I'd gladly test other tubes for collectors. I could capture the output to a video file as well. Thus working tubes could have a higher resale value than "disply only" tubes. Just thinking out loud here...

       Of course, there are several projects in the queue ahead of this one. That is pretty much the IO camera restoration, the Pixicam restoration, the VKR-500 VTR restoration and resumption of the Tiny Ike iconoscope camera project. I have a new video preamp idea to try out. So, stay tuned. Something is bound to happen!

Sunday - May 22, 2016

       I have obtained a couple more image dissector tubes for my collection. I now own seven image dissctor tubes... by definition. The dissector tube receives a lot of disprespect from people who do not understand its physical properties. Allow me to set the record straight. An image dissector tube, as invented by Philo T. Farnsworth, is an excellent image analyzing device for every application except real time Television!

       Why? Because it does not use the property of charge storage as found in the iconoscope, image orthicon, vidicons, CCDs, CMOS sensors or their derivatives. The dissector is an instantaneous sampler. Instead of continuous velocity scanning, imagine a scan that works by stepping from pixel to pixel and dwelling for a finite time on that location. The dissector is an addressable photon counting photomultiplier tube that can do that trick very well. As the sampling position steps , pixel to pixel, let's say it dwells for 200nS. During that short time period, only so many photons will land on that spot. Like very light rain on a given square inch of ground. In that time, in a real world tv camera running at SD rates, only a few hundred photons will be counted. Forget HD rates. At high speeds, the dissector can only detect noise. Hences its low sensitivity in TV applications.

       In a tube with charge storage, the photo site has the entire frame (or field) time to collect photons before being interogated by the electron beam or charge transfer pulse as in a solid state imager. This is typically more than a dozen milliseconds. That is six thousand times longer than the 200 nanosecond real time sampling of the dissector.

       Now, slow the dissector down and install it on a satellite. Let it stare into the darkest parts of space and dwell on each pixel for one second. Though it would take 85.3 hours to scan a 640x480 pixel plane, It would be counting photons for tens of thousands of times longer than a charge storage tube of the same resolution, with the equivelant increase in gain. A charge storage tube would also become saturated by background noise (faint stray light, background heat, RFI or ionizing radiation) long before the scan could be completed.

       Five of my dissetor tubes are precisely of this type. They are officially called steerable photomultipliers and they are used as star trackers in many spy satellites to this day. Remember, vacuum tubes are resistant to high radiation as found in open outer space or during an enemy nuclear attack of the satellite. So, Farnsworth's excellent invention serves where a part for mere entertainment purposes would be a dismal failure.

       My last two image dissector tubes are true imagers. One tube is a one inch diameter with a form factor exactly like a one inch vidicon. The other is a two inch tube that will require winding a special deflection and focus coil in order to apply it. The star tracker tubes have a practical resolution of about 50x50 pixels. Maybe. The true imager tubes are much higher resolution. I can not quote a precise figure as I have no data sheets for any of them and IT&T (sole manufacturer of these tubes) custom built each type to (usually top secret) customer specs. We have a mystery to solve. The dissector is such a simple tube to apply, that I believe I can make at least one them produce pictures with not much effort. I believe the star tracker tubes would work well as a camera for 30/32 line mechanical TV and the full imagers would make great slow scan rate TV cameras. 120 lines at 24 frames per second anyone? Stay tuned!

Sunday - May 15, 2016

       Labguy's World has obtained a [Wesgrove VKR-500] longitudinal VTR. Made in England in 1965 and sold as a do-it-yourself kit! Formerly owned by John Fletcher. I only recently learned that John passed away 11 years ago. A restoration project for this recorder is inevitable. Please stay tuned.

Suday - April 10, 2016

       Added a new project today. [5FPn CRT Tester] project. Obtained three tubes. 5FP5, 5FP7A and 5FP25. Had to make these old 1940s display tubes light up, focus and scan. Just to see the pretty colors of the various flourescent phosphors. Each optimized for a particular purpose. Enjoy!

Saturday - February 13, 2016

       Updated part 2 of the [color mechanical TV] project. The new high powered color LEDs are working extremely well. Visit the article and scroll down for the latest images. Enjoy!
